New Product ! Musical Fidelity M1SDAC รองรับ Bluetooth,Headphone,Pre Amplifier
« เมื่อ: 10 กุมภาพันธ์, 2013, 12:43:04 PM »












Model : M1SDAC


ราคา : 42,000 บาท


- Headphone amplifier, Pre Amplifier, DAC/ADC, Bluetooth reciever
 - Styled in line with the rest of the M1 range
 - Available in Black or Silver
 - 2 x COAX inputs (will accept up to 24bit/192kHz)
 - 1 x AES/EBU balanced input (will accept up to 24bit/192kHz)
 - 1 x USB input (will accept up to 24bit/192kHz, asynchronous)
 - 1 x Optical input (will accept up to 24bit/96kHz)
 - 1 x Bluetooth V 2.1 apt-x receiver (up to 24bit/48 kHz and up-sampled to 24bit/192kHz)
 - 2 x RCA Analogue inputs
- 1 x COAX output
 - 1 x Optical output


DAC Section

The M1 SDAC features true internal up-sampling with asynchronous re-clocking at 24bit/192kHz, and features a host of connectivity possibilities - making it compatible with virtually any kit.

There are six digital inputs included: 2 x coaxial, 1 x optical, 1 x AES/EBU Balanced, 1 x asynchronous USB and Bluetooth apt-X at 48kHz.

The USB input of the M1 SDAC features the technologies employed in the VLINK 192 - enabling asynchronous 24bit/192kHZ usage, a feature which is rare at this price and aids the SDAC in producing class-leading performance.

The M1 SDAC's apt-X Bluetooth module is also a key selling point - borrowing from the Musical Fidelity M6 DAC's advanced technologies. The I2 bus is taken directly from the Bluetooth receiver module to the up-sampling circuitry - meaning all other electronics are bypassed. This solution is both elegantly simple and complex to implement, but is a circuit design which certainly yields exceptional results. The results of its innovative circuitry are clear, and help in forging Bluetooth as a true audiophile solution.

As if the SDAC wasn't already fully-featured enough, it also includes an analogue to digital converter (ADC) which ensures that a digital output is given for any selected input.

Headphone Amplifier Section

The headphone amplifier featured on the M1 SDAC is high performance and features ultra-low output impedance with outstanding linearity and low distortion with a capability to output 2 watts at peak. The headphone functionality is not simply an after-thought as with many products, and has been painstakingly designed with a view to offering superb and accurate audio reproduction.

Musical Fidelity are so confident in its ability that they claim it will "drive any headphone with ease and authority". For added convenience, both the Headphone and Pre-amplfiier outputs have independently "remembered" volume settings.
